Superposition Theorem in Bangla Example 04(YouTube Tutorial)

The superposition theorem is unquestionably one of the most powerful in the field. Condition: Have Two or More Sources involve in Circuit Figure(Or Network) Superposition Theorem state that the current through or voltage across any component of a network is equal to the algebraic sum of the currents or voltages produced separately by each source. Steps to solve network through Superposition Theorem:-
1. Consider only one source and replace other sources with their internal resistance( For Ideal current source replaced by "open" circuit and for ideal voltage source replaced by "short" circuit) Then find the required component current through or voltage across and mark the current flowing direction or voltage polarity.
2. Take another source and replace other sources and find current through or voltage across of that component and mark the current flowing direction or voltage polarity.
3. Repeat this process according to numbers of sources involve in given network.
4. Take Algebraic sum of all current or voltages which produced by each sources independently. Note: Algebraic Sum means take current or voltage direction or polarity in consideration. Prerequisites: Series-Parallel Circuit, Ohms Law, Kirchhoff's Law(KVL and KCL).
Team: SM Subject: Electrical and Electronics Engineering Topic: Network Theorem Lecture: Superposition Theorem
