Thevenin to Norton(vice-versa) Equivalent Circuit Transformation in Bangla(YouTube Tutorial)

THEVENIN's THEOREM Thevenin's theorem state that any two-terminal linear bilateral electric network can be replaced by an equivalent electric circuit consisting of a voltage source and a series resistor.

Step By Step Network Analysis Through Thevenin's Theorem

Finding Rn(Thevenin's Resistance): Remove Load Resistor(mark open terminals), Replaced all sources(Voltage Source, Current Source) by their internal resistance.(Internal Resistance of voltage source="short circuit" and Internal Resistance of current source=" open circuit"

Finding Vth(Thevenin's Voltage)= Reconnect all sources to their original position and measure voltage between marked terminals of the open circuit.

Draw Equivalent Thevenin Circuit.
NORTON's THEOREM
Norton theorem state that any two-terminal linear bilateral electric network can be replaced by an equivalent electric circuit consisting of a current source and a parallel resistor.

Step By Step Network Analysis Through Norton's Theorem

Finding Rn(Norton Resistance): Remove Load Resistor(mark open terminals), Replaced all sources(Voltage Source, Current Source) by their internal resistance.(Internal Resistance of voltage source="short circuit" and Internal Resistance of current source=" open circuit"

Finding In(Norton Current)= Reconnect all sources to their original position and place "short circuit" between marked terminal. measure the current of the short circuit.

Draw Equivalent Norton Circuit.

Team: SM
Subject: Electrical and Electronics Engineering
Topic: Network Theorem
Lecture: Norton's Theorem
