Thevenin's Theorem Step by Step in Bangla Example 06(YouTube Tutorial)

Thevenin's theorem state that any two-terminal linear bilateral electric network can be replaced by an equivalent electric circuit consisting of a voltage source and a series resistor.

Step By Step Network Analysis Through Thevenin's Theorem

Finding Rn(Thevenin's Resistance): Remove Load Resistor(mark open terminals), Replaced all sources(Voltage Source, Current Source) by their internal resistance.(Internal Resistance of voltage source="short circuit" and Internal Resistance of current source=" open circuit"

Finding Vth(Thevenin's Voltage)= Reconnect all sources to their original position and measure voltage between marked terminals of the open circuit.

Draw Equivalent Thevenin Circuit.

Team: SM
Subject: Electrical and Electronics Engineering
Topic: Thevenin's Theorem
Lecture: Thevenin's Theorem
Lecturer: Md. Shahjalal Hussain 👍👍FB Page : https://goo.gl/9MSQBg My channel: https://goo.gl/oU847H Full Playlist: https://bit.ly/2H7zKT1
